Note: The glass lens has the LOGO.

Note: This LCD kit compatibles with GG, SMS and SG-1000 games.

Note: If you purchase the LCD kit only, you will need to trim the shell by yourself. Shell trimming is quite labor-intensive, so we recommend buying our LCD kit together with the matching shell.

MAX display size IPS LCD. The display size is 16% larger than the original screen.
It also can set to the original display size.

Installation is so easy: You only need to remove one original screen, two fuses and one resistor.

1. Support Sega single chip motherboard and dual chip motherboard:
–Single chip motherboard:1 ASIC PCB revisions 837-9130/837-9024/837- 8560
–Dualchip motherboard:2 ASIC PCB revisions 837-7996/837-7719-01 VA0/837-7398-03

Note 1: Doesn’t supported: Majesco Game Gear VA4/VA5.
Note 2: The motherboard with the “MADE IN TAIWAN” logo on the motherboard of the game console does not support.

Description:

1. 640×480 display resolution. HD IPS LCD.
2. Pre Laminated Glass Screen.
3. The display size is 16% larger than the original screen. It also can set to the original display size
4. Wide View angle up to 178 degree.
5. Built-in OSD Menu!
6. High brightness, 15 brightness levels.
7. Retro pixel Effects: Normal, Retro pixel, Horizontal Scanline, Vertical Scanline.
8. Built in 3 LCD Aspect Ratio. Full Screen, Original Display sizey, Small size.
9. 8 color modes.
10. Image position adjustable. (It has no effect in full screen)
11. FPC connect cable design. Simpler wiring and easier installation.

OSD Menu Operation:

-Press the START+1+2 buttons for 1 second to activate the OSD Menu.
-Press the ‘START’ button to select the adjustment item when OSD Menu activated.
-Press the ‘1’ or ‘2’ button to adjust the item when OSD Menu activated.

Packing including:   (Only LCD Kit)

1x Laminated Backlight LCD screen.
1x PCB board.
1x FPC connect cable.
1x Double-sided tape.
1x 0 Ohm resistor.
Several red wires.

Or:   (LCD Kit with shell case)

1x Laminated Backlight LCD screen.
1x PCB board.
1x FPC connect cable.
1x Double-sided tape.
1x 0 Ohm resistor.
Several red wires.
1x pre-cut shell case, 1 set buttons, 1 set Rubber Pad, 1 set Sticker label,1 set screws.

Note: If you purchase the LCD kit only, you will need to trim the shell yourself. Shell trimming is quite labor-intensive, so we recommend buying our LCD kit together with the matching shell.

Instructions 1:

(Single chip)

Instructions 2: (Dual chip)
